Model HBS-62.5 Digital Display Low Load Brinell Hardness Tester For Unquenched Steel And Cast Iron

Brand Name : SAMYON

Model Number : HBS-62.5

Certification : ISO

Place of Origin : CN

MOQ : 1set

Price : Can be negotiated

Payment Terms : Western Union, MoneyGram, , T/T, D/P, D/A

Supply Ability : 100sets per week

Delivery Time : 3-5days

Packaging Details : Wooden case

Name : Hardness tester

Standard : ISO 6506-2:2017

Test force : 9.807, 49.03

Measuring range : 8-650HBW

Depth of throat : 125mm

Max sample height : 180mm

Contact Now

Model Hbs-62.5 Digital Display Low Load Brinell Hardness Tester

Application:

It is mainly used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc. It is especially suitable to determine the Brinell hardness of soft metal materials and small parts.

Standard:

ASTM E10-2018 Standard Test Methods for Brinell Hardness of Metallic Materials

ISO 6506-2:2017 Metallic materials - Brinell hardness test - Part 2: Verification and calibration of testing machines

GB/T 231.2-2012 Metallic materials - Brinell hardness test - Part 2: Verification and calibration of testing machines

Parameters:

Item Name Details
1 Test force

9.807, 49.03, 98.07, 153.2, 294.2, 612.9N

(1, 5, 10, 15.625, 30, 62.5kgf)
2 Measuring range 8-650HBW
3 Depth of throat 125mm
4 Max. height of test piece 180mm
5 Magnifications of measuring system 125X, 50X
6 Min. scale value of the optical micrometer 0.5μm
7 Dimension 580 x 260 x 730mm
8 Weight approx. 90kg
9 Power 220/110V AC, 50 or 60Hz

Features:

1. Precision conforms to GB/T 231.2, ISO 6506-2 and ASTM E10

2. Large LCD screen, menu operating, complete function with data processing, hardness value conversion and so on

3. Automatic testing process, no human operating error

Standard accessories:

Large flat anvil: 1 pc.

Small flat anvil: 1 pc.

V-notch anvil: 1 pc.

Tungsten carbide ball penetrator: Φ1, Φ2.5mm, 1 pc. each

Brinell standardized block: 2 pcs.

Printer: 1 pc.
